Zeiss Victory 10 x 42 T* RF
Zeiss Victory 10 x 42 T* RF
Zeiss Victory 10x42 T* RF
Experienced hunters can always rely on their senses. Nevertheless, with the right equipment, they can go further than this and transform intuitions into certainties.
The Rangefinder System is a laser rangefinder with an integrated real-time ballistics computer. The consideration of all relevant factors and customisation with the aid of the ZEISS Hunting App ensures precisely placed shots at any distance. The RF family offers a choice of four models: the RF 8 × 42 and 10 × 42 for daylight hunting and the RF 8 × 54 and 10 × 54 for hunting into the twilight hours.
Measuring within seconds
The rangefinder determines the precise target distance up to a maximum range of 2,300 metres.
Bluetooth synchronisation with ZEISS Hunting App
The capabilities of the rangefinder system are perfected by the ability to synchronise it with the ZEISS Hunting App via Bluetooth. Every measurement takes the physical and environmental factors, such as temperature and air pressure, into account when making the calculation.
Transfer of personal ballistic data
Storage capability for up to nine personalised ballistic profiles, that can be set up within the ZEISS Hunting App. Thanks to the Bluetooth function it is possible to import personal ballistic data from the ZEISS Hunting App to the Victory RF.
Calculate precise setting for BDC (ASV)
The various measuring functions of the rangefinder take a multitude of relevant data into account and use them to calculate the precise setting for the BDC (ASV).
Detaljer
Magnification |
10 × |
Effective lens diameter |
42 mm |
Exit pupil diameter |
4.2 mm |
Twilight factor |
20.5 |
Field of view at 1,000 m (yds) |
115 m (345 ft) |
Subjective viewing angle |
63° Ww |
Close focusing distance |
2.5 m (8.2 ft) |
Diopter adjustment range |
− 4.0 | + 4.0 dpt |
Exit pupil distance |
16 mm |
Pupil distance |
53.5 – 76 mm |
Lens type |
FL |
Prism system |
Abbe-König |
Features
LotuTec | Nitrogen filled |
+ | + |
Water resistance |
100 mbar |
Measuring range |
10 – 2,300 m (11 – 2,500 yds) |
Measuring accuracy |
± 1 – 600 / ± 0.5 % > 600 m (yds) |
Measuring duration |
< 0.3 Sec |
Laser wavelength |
905 nm |
Laser beam divergence |
1.6 × 0.5 nm |
Battery |
1 × 3V Type CR 2 |
Battery life at +20°C |
> 2.500 × |
Physical
Operating temperature |
− 30°C | + 63°C (− 22°F | + 145°F) |
Length |
166 mm (6.5 ") |
Width at an interpupillary distance of 65 mm |
130 mm (5.1 ") |
Weight |
960 g (33.9 oz) |
